STANDARD MATERIALS
| PART NAMES | MATERIALS |
|---|---|
| BODY | NOTE 1) |
| SEAT CONNECTOR | BODY MAT'L + N.C coating |
| GUIDE SEAT | 410SS or 420SS + STL. |
| BALL | 316SS or INCO + N.C |
| CAGE | 316SS or 410SS |
| STEM | A286 or EQ |
| GASKET | 316LSS or 630SS |
| GLANDPACKING | GRAPHITE |
Note
1) All the Stainless Steel Available
-ASTM A105, ASTM A182-F11 / F22 / F91
SPECIFICATIONS
1) Valve Size : 1" ~ 4"
2) Applicable Rating : ASTM 150#~4500#
3) Temperature : Up to 600℃
4) Code & Standard : API, BS, ASME, ASTM
Design by ASME B16.11 / 16.25 / 16.34 / MSS-SP-72
5) Allowable Seat Leakage : V, VI, Zero
6) Main features
- 2-Piece Body
- End Conn. : R.F / RTJ / SW / BW
- Floating Ball Type
- Intergral Seat for ZERO Leakage
- Manual or Puenmatic, MOV Operating
