STANDARD MATERIALS
| PART NAMES | MATERIALS |
|---|---|
| BODY | NOTE 1) |
| BONNET | NOTE 1) |
| SEAT | Stainless Steel |
| STEM | ASTM A276-304 |
| GASKET | SPIRAL WOUNDED GRAPHITE |
| BONNET BOLT | Stainless Steel |
| GLAND PACKING | GRAPHITE |
| GLAND | ASTM A276-316 |
NOTE
1) Forged Stainless Steel, ASTM A351-CF8(M)
SPECIFICATIONS
1) Valve Size : 1/2" ~ 24"
2) Applicable Rating : ASME 150# ~ 2500#, KS 10K ~ 40K
3) Temperature : Down to -196℃
4) Code & Standard : BS, ASME, ASTM, KGSC
Designed by BS6364, ASME B16.34, and ASME B16.11/16.5
5) Allowable Seat Leakage : ASME Class Ⅲ, Ⅳ, Ⅴ, Ⅵ, BS6364
6) Constructions
- End Connection : Socket-Welded, Butt-Welded, or Flanged Type
- Long Extended Bonnet
- Actuator : Cylinder or Diaphragm Type
- Quick Change Typed Trim
