STANDARD MATERIALS
| PART NAMES | MATERIALS |
|---|---|
| BODY | NOTE 1) |
| BONNET | NOTE 1) |
| SEAT | CAST STEEL or SOFT-PCTFE & GRAPHITE |
| BALL | ASTM A276-304/316 or A351-CF8(M) |
| STEM | 316SS+H.cr or Cond. B |
| GASKET | SPRIAL WOUNDED GRAPHITE |
| GLAND PACKING | PTFE or GRAPHITE |
Note
1) All the Stainless Steel Available
- CAST STEEL, STAINLESS
SPECIFICATIONS
1) Valve Size : 1" ~ 36"
2) Applicable Rating : ASTM 150#~1500#
3) Temperature : -196℃ to 570℃
4) Code & Standard : API, BS, ASME, ASTM, KGSC
Designed by ASME B16.11 / 16.34 / 16.5 / API 6D
5) Allowable Seat Leakage : IV, V, VI
6)End Conn. : R.F / RTJ / SW / BW
7)Fire Safety Construction (CERTI. By TÜV)
8)Additional Equipments
Pneumatic & MOV Actuator
Positioner , Air set , Solenoid V/V ETC.
