STANDARD MATERIALS
| PART NAMES | MATERIALS |
|---|---|
| BODY | NOTE 1) |
| BONNET | NOTE 1) |
| SEAT | ASTM A105-(H.F) |
| DISC | ASTM A217-CA15 |
| STEM | ASTM A276-410 |
| GASKET | GRAPHITE |
| HABDWHEEL | ASTM A197 |
| GLAND PACKING | GRAPHITE |
| GLAND | ASTM A276-410 |
NOTE
1) HIGH TEMP. : ASTM A216-WCB, ASTM A217-WC1 / WC6 / WC9,
LOW TEMP. : ASTM A352-LCB / LC1 / LC2 / LC3
SPECIFICATIONS
1) Valve Size : 2" ~ 24"
2) Applicable Rating : ASME 600# ~ 2500#
3) Temperature : Up to 500℃
4) Code & Standard : API, BS, ASME, ASTM, KGSC
Designed by ASME B16.10 / 16.25 / 16.34 / 16.5,
API 598 / 600
5) Constructions
- End Connection : Butt-Welded Type
- PSB (=Pressure Seal Bonnet) Type
- Full Bore
- Manual or Motor Operated
(Pneumatic, Electric, or Hydraulic)
