STANDARD MATERIALS
| PART NAMES | MATERIALS |
|---|---|
| BODY | NOTE 1) |
| COVER | NOTE 1) |
| SEAT | ASTM A105-HF |
| BALL | ASTM A276-304 |
| GASKET | GRAPHITE |
| COVER BOLT | ASTM A193-B7 |
NOTE
1) ASTM A105, A182-F304(L) / F316(L) / F22 / F5 / F9 / F317/ F347 / F321
SPECIFICATIONS
1) Valve Size : 1/2" ~ 2"
2) Applicable Rating : ASME 150# ~ 1500#
3) Temperature : Up to 500℃
4) Code & Standard : API, BS, ASME, ASTM
Designed by ASME B16.11 / 16.34 / 16.5, and BS5352
5) Constructions
- End Connection : Socket-Welded or Flanged Type
- BC (=Bolted Cover) Type
- Full Bore / Reduce Bore
