STANDARD MATERIALS
| PART NAMES | MATERIALS |
|---|---|
| BODY | NOTE 1) |
| BONNET | NOTE 1) |
| SEAT | ASTM A276-304(L) / 316(L)-(H.F) |
| DISC | ASTM A351-CF8(M) / CF3(M), A276-304(L) / 316(L)-(H.F) |
| GASKET | SPIRAL WOUNDED GRAPHITE |
| ARM | ASTM A351-CF8(M) / CF3(M) |
NOTE
1) Forged Steel, ASTM A182-F304(L) / F316(L)
SPECIFICATIONS
1) Valve Size : 1/2" ~ 2"
2) Applicable Rating : ASME 150# ~ 1500#
3) Temperature : Down to -196℃
4) Code & Standard : BS, ASME, ASTM, KGSC
Designed by BS6364, ASME B16.34, and ASME B16.11/16.5
5) Shell & Seat Leak Test : ASME B16.34
6) Constructions
- End Connection : Socket-Welded or Flanged Type
- Full Bore / Reduce Bore
