Name

GAUGE HATCH

Model SNB210
Series Inert Gas Blanketing Device
Product Description

B(mm)L(mm)H(mm)Weight(kg)Minimum
set pressure
Remarks
30030030017.5+25mmH2OWithout inlet pressure regulator
30052030022+25mmH2OWith inlet pressure regulator

The equipment to automatically provide inert gas to Vapor Space in the storage tank.

SNB 210 : Pilot Operated Type


Specifications

Set pressure(open pressure)range+25mmH2O to + 2,000mmH2O
Minimum inlet pressure2kg / ㎠
Operating temperature range-28 to 100 DEG. C(-18 to 212 DEG.F)
Sensor port connection1/2" NPT or 1/2"PT
