| Name |
HEAT SHIELD |
| Series | ON/OFFSHORE (HEAVY STRUCTURE MODULE) |
Project : Ichthys FPSO Project
Site : Australia
Shipyard : DSME
Engineering : DSME
End-user : INPEX
Delivery : 4th Quarter of 2014
Size : 2-7 X 1-4.9 X 6.9m
Weight : Total 113Tons
Scope: Shop/Field Fabrication Drawings
Procurement of bulk materials
Fabrication of piping, stru and RACK assembly
Final Vendor Documents
Main Material : Structure : AH36, SS316L
Piping : N/A
