Name

TYPE FLAME ARRESTER

Model KSFD
Series Land-Based-Products(Flame Arrester)
Catalog topsafe__117838_ixueqh-ZmDp3X7.pdf
Product Description

KSFD TYPE FLAME ARRESTER

Benefits
Meet USCG, IMO MSC/Circ,677 & EN ISO 16852 requirements
Designed for Detonation & Deflagration proof
Maximum Capacity & Minimum Pressure drop
Capability of of absorption of high shock pressure
Quick & Easy removable element
Very easy cleaning & maintenance
Available vertical & horizontal installation
High quality corrosion & chemical resistance


INTRODUCTION
The model KSFD inline detonation flame arrester is designed, manufactured and tested according to British Standard Specification Code BS 7244, EN ISO 16852, USCG and IMO MSC/Circ,677.
The KSFD detonation flame arresters provide protection against flame propagation in piping systems that are manifolded or have long runs.
The arresters are designed to stop an ignited flammable vapor mixture travelling at subsonic or supersonic vapor velocities.
They are also designed to protect against continuous burning against the 316LSS flame cell for a specific period.
The atandard flame cell is suitable for NEC group D or IEC IIA gases. Cells for other gas groups are available as additional extras.
The flame arresters are available with either carbon steel (epoxy coated), 304SS, or 316SS housing with 316LSS flame cells.
Sizes range from 25mm to 300mm. Standard flanges are ANSI 150lb and other connections are available upon request.


TYPE FLAME ARRESTER
Meet USCG, IMO MSC/Circ,677 & EN ISO 16852 requirements
Designed for Detonation & Deflagration proof
Maximum Capacity & Minimum Pressure drop
Capability of of absorption of high shock pressure
Quick & Easy removable element
Very easy cleaning & maintenance
Available vertical & horizontal installation
High quality corrosion & chemical resistance
