| Name |
Panel Stiffener Welding Robot System for Sub Assembly |
| Series | Welding System |
The outline of equipment
- This is a welding equipment for sub assembly panel and stiffener by multi axes robot. Welding position is recognizing by DNC data, and seam tracking is by ARC sensor equipped with robot head.
Welding Process
- Welding Process : FCAW 1Pole x 2Head = 2Poles
- 전극 구성 : 1Poles
- 용접 자세 : 1F
- 적용 Wire : φ1.2, φ1.4, φ1.6mm
- Welding Speed : 100mm ～ 800mm/min
