Features
• 3D map developed with SAMYUNG ENC’s / NAVIONICS proprietary technology
• High intensity and high definition display with high resolution TFT Applied
• backlighting adjustable to 10 different brightness levels
• NAVIONICS Platinum+ available utilizing SD card input
• Plays movies, videos and music from SD or USB input
• 512/1024MB internal memory and embedded with standard SAMYUNG S-MAP
• Individual navigation GOTO & MOB buttons
• NMEA(0183/2000) interface (AIS, NAVTEX, DSC, Data repeater, Fuel control etc.)
• Multiple language support (English, Chinese, Russian, etc.)
• DGPS (including WAAS, MSAS, EGNOS) provide greatest accuracy possible
• Excellent user friendly menu and icons
• Perfect navigational interface with Auto Pilot / Engine Controls
• Utilizes dual frequency system (50/200 kHz) for detection of small fish groups (NF120)
• Features upgraded auto range, gain output and pulse length in our latest fish finding circuitry (NF120)
• Utilizes high performance transduce for detection of individual and small fish (NF120)
Specifications
• Display : 12”LED Backlight
• Receiving channel & Tracking satellite : 50 Channels 16 Satellites / Digital 16 Channels multi-tracking type
• Supply voltage : 11 to 35 V DC Approx. 40W
• Operating temp : -10℃ ~ 50℃
• Display mode : normal, true-motion, course-up, northup, head-up function
• Alarms : Arrival radius, anchor, XTE, danger, too shallow, too deep, fish, temperature, temperature rate, low battery, low fuel(optional), loss of DGPS fix, radar guard zone, dangerous AIS vessels.
• Chart/User card : SAMYUNG 2D/3D, NAVIONICS Platinum+ / SD Card 2 slot, USB 1slot
• Waypoints : 30,000 waypoints (Event Mark : 48, Mark Color : 16)
• Routes : 100 Routes, with up to 100 points each
• Tracks ; By time or distance, 10 tracks of 30,000 points
• Chart datums : 216 Chart datums(1/2000~1/37,500,000)
• Chart scale : 3m~1,500m
• Interface : NMEA 0183, NMEA 2000
• Frequency : 50/200KHz
• Output : 600W, 1kW
• Depth Range : 3m~1,500m
• Color Display : 16 colors
• Brightness : 10-step
• Screen Moving Speed : super fast, fast, medium, low, stop
• Battery Voltage Display : Voltage number dispaly
• AUTO GAIN Adjustment : OFF/ON
• A-Mode Display : OFF/ON
• Demo Dispaly : OFF/ON
• Weak Color Removal : 0% ~ 75%
