UMI 1075 INSULATION
10 ton typical weight saving on Destroyer
Improved Thermal & Acoustic performance over competitors
Description
UMI 1075 Themal and Acoustic InsulationDowmarine - UMI1075 Marine Insulation is a light weight, water repellent, glass wool hull board, for use as a thermal and acoustical insulation in marine applications. The product is produced by a flame attenuation process incorporating a flame retardant, thermoset binder system.
MTI 1046 - MARINE FIBRE BOARD
Fully approved for in-service MOD (UK) Ships.
DEF STAN 711 and DEF STAN 713 Certified.
Description
Marine Thermal and Acoustic InsulationIncombustible Hullboard from Trelleborg Applied Technology is a lightweight, semi-rigid board insulation made from felted glass fibres in a nominal density of 2.9 pf (46.5 kg/m3). MTI 1046 Hullboard is characterised by a low organic content.
Characteristics
Dowmarine - UMI1075 Marine Insulation products are manufactured with a patented controlled fibre diameter and density to insure consistent thermal and acoustic performance.
Maximum performance temperature for un-faced products are 232ºC (450ºF)
High Thermal Performance With a low “k” factor of 0.23 Btu•in/(hr•ft2•°F) at 75°F mean temperature (0.033 W/m•°C at 24°C), MTI 1046 Hullboard is highly effective in reducing heat transfer. Operating Temperature Limit : 450°F (232°C)
Qualification
Dowmarine - UMI1075 Marine Insulation products meet the performance requirements of:
DEF STAN 711
DEF STAN 713
MIL-I-742F
MIL-I-22023D
DOD-I-24688.
