Features
· Excellent interior pressure resistance & impact resistance
· Excellent durability & non-flammability
· Minimization of building load as a light reduction product
· Excellent corrosion resistance due to epoxy powder coating
· Recycling allowed after replacement of only finish materials upon transfer & disposal
Usage
· Uses-General office, plant. Power plant, disaster prevention center
· Machine room, various equipment room. Vessel & marine plant
· Research lab, data processing room. Broadcast facility room
Finishing
· Conductive Tile
· Deluxe Tile
· PVC Vinyl Sheet
· Carpet
View Blueprints
| Model | IHSF-I | Test |
| Interior Pressure Resistance | SP Type 4,900N(500kgf) Less than 4mm upon pressure application | O |
| R Type 2,900N(300kgf) Less than 4mm upon pressure application | O | |
| Length | Less than ±0.5mm of one-side length | O |
| Flatness | Less than 0.1% of one-side length | O |
| Perpendicularity | Less than 1mm on peripheral part Less than 2mm otherwise | O |
| Impact Resistance | No occurrence of splitting, cracking | O |
| Electrification | Human body voltage Vp < 3000 V | O |
| Leakage Resistance | 1x 105Ω < R< 2X1010Ω | O |
| Panel Size | 600x600mm |
| Panel Weight | 10kg/매 |
| Installation Weight | 28kg/m2 |
| Upper Plate | Hot-rolled steel plate |
| Lower Plate | Cold-rolled steel plate |
| Coating | Electrostatic powder coating |
