| Hose Size | Hose I.D. | Hose O.D. | Working Pressure | Burst Pressure | MIN.Bend Radius | Weight | |||||
| mm | Inch | mm | Inch | bar | psi | bar | psi | mm | Inch | kg/m | |
| 3.4″ | 19.0 | 0.75 | 33.0 | 1.30 | 420 | 6090 | 1680 | 24360 | 280 | 11.0 | 1.56 |
| 1″ | 25.4 | 1.00 | 38.7 | 1.52 | 380 | 5510 | 1520 | 22040 | 340 | 13.4 | 2.09 |
| 1-1/4″ | 32.0 | 1.25 | 49.8 | 1.96 | 350 | 5070 | 1400 | 20000 | 420 | 165 | 3.90 |
| 1-1/2″ | 38.0 | 1.50 | 57.4 | 2.26 | 350 | 5070 | 1400 | 20000 | 500 | 20.0 | 4.96 |
| 2″ | 50.8 | 2.00 | 71.1 | 2.80 | 350 | 5070 | 1400 | 20300 | 635 | 25.0 | 7.09 |
| APPLICATIONS | – Very high pressure line – Hydraulic fluids, glycol, mineral oil, fuels, lubrication, emulsion, hydrocarbons |
| TEMPERATURE RANGE | 40℃ to + 100℃ (-40°F to + 212°F) |
| REINFORCEMENT | Four high tensile steel spirals |
| REFERENCE SPECIFICATION | EN856 R13, SAE100R13 |
