The explosion by oil mist accompanies increase of instant energy with rapid increase of temperature and pressure.
Crankcase Explosion Relief Valve is required subject to reduce damage from secondary explosion, and to protect human and machine from the primary explosion.
Characteristics
Crankcase explosion Relief Valve is essential to protect the human life and machines from explosion caused by oil mist
▣ Advantage
- Efficient protection for man, machine and plant
- Continuous operation after an explosion
- Approved safety device
- Responds and opens even at a very low pressure setting(standard 0.05 bar and 0.075 bar below 266 sizes)
- Can be installed in any position both horizontal and vertical
▣ Dimensions
Model | A | B | C | D | E | F | G | H | I | J | K | M | Opening Area ㎠ |
KSRV-735(H) | 1018 | 705 | 989 | 265 | 318 | 425 | 12 | 12xM16 | 796 | 17 | 912 | 23 | 3904 |
KSRV-645(H) | 930 | 617 | 894 | 226.5 | 275 | 378 | 12 | 12xM16 | 700 | 17 | 840 | 23 | 2990 |
KSRV-565(H) | 843 | 541 | 809 | 196 | 250 | 335 | 12 | 12xM16 | 615 | 17 | 735 | 23 | 2999 |
KSRV-480 | 754 | 460 | 724 | 164 | 214 | 287 | 12 | 8xM16 | 530 | 17 | 644 | 23 | 1662 |
KSRV-420 | 693 | 400 | 659 | 141 | 186 | 251 | 12 | 8xM16 | 465 | 17 | 579 | 23 | 1257 |
KSRV-345 | 561 | 325 | 552 | 147 | 182 | 214 | 10 | 6xM16 | 390 | 9 | 516 | 17 | 830 |
KSRV-320 | 522 | 305 | 512 | 136 | 173 | 197.5 | 10 | 6xM12 | 355 | 9 | 471 | 17 | 731 |
KSRV-266 | 492 | 252 | 471 | 89 | 130 | 170 | 10 | 6xM12 | 302 | 17 | 422 | 23 | 499 |
KSRV-224 | 443 | 210 | 424 | 75 | 109 | 142 | 8 | 6xM12 | 255 | 10 | 371 | 15 | 346 |
KSRV-204 | 415 | 190 | 404 | 65 | 103 | 132.5 | 8 | 6xM12 | 235 | 11 | 351 | 17 | 284 |
KSRV-173(A) | 382 | 160 | 367 | 55 | 83 | - | - | 6xM10 | 203 | 11 | 314 | 17 | 201 |
KSRV-173(B) | 382 | 160 | 367 | 55 | 83 | 115 | 8 | 6xM10 | 203 | 11 | 314 | 17 | 201 |
KSRV-162 | 366 | 150 | 355 | 50 | 83 | - | - | 6xM10 | 190.5 | 10 | 302 | 16 | 177 |
KSRV-122 | 326 | 110 | 314 | 38 | 61 | - | - | 6xM8 | 150 | 10 | 260 | 16 | 93 |
KSRV-98 | 299 | 87 | 283 | 31 | 50 | - | - | 4xM8 | 122 | 7 | 230 | 12 | 59 |
※ H means Hinge type Valve.
