Specifications

Use : Middle speed print for cable of small size
Applicable : Cable dia below 10mm
Type : Gravure direct print
Line speed : Max. 250m/min
Line center : 1,000mm
Name roll : 100×20×30mm
Print pitch : 314mm
Print head/select : 2Set, by air cylinder
Pinch roll : 80mm
Ink supply : Ink moter/ink mixing roll
Drive : None
Ink case : Content capacity 3 liters
Power/pnermatic capacity : 2Ph AC 220V 50/60Hz, min 5.0 psi
Layout dimension : W 650, B 450, H 1,500mm

Option

1. Caster or rail
2. Large size 15~100mm

Diagram
