Anti-Heeling System

Series Hydraulics
Catalog norr-systems-korea_121892_lqdlau-FBVC66W.pdf
Product Description

The Anti Heeling System enables safe and continuous loading or unloading operations for e.g. container vessel, RoRo carrier, ferries, project carriers, heavy lift and offshore construction vessels in much reduced time. The heeling compensation is automatically achieved by transferring ballast water between the heeling tanks, controlled by Norrsystems Korea’s microcomputer HOMIP, based on continuous measurement of the heeling angle.


The type approved system can operate with reversible or non-reversible pumps in 3 different sizes and is using Norrsystems Korea’s Remote Controlled Valves to enable ballast water flow.

The complete system includes:

Anti-Heeling Control Panel

Pump Starter Panel

Heeling Pump

Heeling Valves (hydraulic or pneumatic actuators)

Valve Remote Control

Level Transmitters and Switches

Inclinometer

HOMIP microcomputer


Anti Heeling System

Our Anti-Heeling system is desigened to automatically balance the vessel in upright position by pumping ballast water of ballast tank during loading and unloding.


> The main components of system are :

Anti-heeling Control Panel

Pump Starter Panel

Heeling Pump

Heeling Valves

Level Transmitters

Level Switches

This system will initiate the necessary actions to transfer the water from the starboard to port heeling tanks and vice versa. It can be used in conjuction with a reversible pump and remote controlled hydraulic, pneumatic or electric valves.

The precision inclinometer mounted athwart to the ship's direction measures the prevailing heeling angel signal to the main PLC. The main CPU installed in anti-heeling panel (flush type)
