Side Entry 2 Piece Floating Ball Valve
Side Entry 2 Piece Floating Ball Valve(FLO-MAX) :
Floating Ball Design
ANSI 150-300
2 Piece Split Body, Full Bore, Reduced Bore,
End Connection : RF, RTJ, BW Type, Hub.
Actuation : Lever, Gear, pneumatic, electric, hydraulic actuator
Anti-Static, Fire Safe API 6FA & API 607
Size : 1/2" inclusive through to 12"
Temperature : -196° C ~ 450° C (-320° F ~ 850° F)
Forged Side Entry 2 Piece Ball Valve
Side Entry 2 Piece Ball Valve
ANSI Class-150-300-600-900-1500-2500
2 Piece Split Body, Full Bore, Reduced Bore,
End Connection : RF, RTJ, BW Type, Hub.
Actuation : Lever, Gear, pneumatic, electric, hydraulic actuator
Anti-Static, Fire Safe API 6FA & API 607
Size : 1/2" inclusive through to 36"
Temperature : -196° C ~ 450° C (-320° F ~ 850° F)
Side Entry 2 Piece Trunnion Mounted Ball Valve
2 Piece Side Entry Trunnion Mounted Ball Valve
ANSI Class-150-300-600-900-1500-2500
Size: 2" inclusive through to 48"
End Connection : RF, RTJ, BW Type, Hub.
Actuation: Gear, Pneumatic, Electric, Hydraulic
Temperature: -196°C ~ 450° C (-320° F ~ 850° F)
Side Entry 3 Piece Trunnion Mounted Ball Valve
Side Entry Trunnion Mounted Ball Valve :
Class ANSI 150-300-600-900-1500-2500
3 Piece Split Body Design, Reduced and Full Bore,
Size: 6" inclusive through to 60”
End Connection : RF, RTJ, BW Type, Hub.
Actuation: Gear, Pneumatic, Hydraulic, Electric.
Fully Certified in accordance with API 6D
Antistatic, Fire Safe API 6FA, & API 607
Sour Service Requirements to NACE MR 0175
Top Entry Trunnion Mounted Ball Valve
Top Entry Trunnion Mounted Ball Valve
Class ANSI 150-300-600-900-1500-2500
Size: 2" inclusive through to 60"
End Connection : RF, RTJ, BW Type, Hub.
Top Entry Valve enables periodic inspection and service without removing the Valve Body from the Pipeline.
Certified in accordance with API 6D, Fire-Safe API 6FA, API 607, Anti-static, Sour Service Requirements to NACE MR 0175
Wedge Seal Side Entry Ball Valve
Wedge Seal Side Entry Ball Valve
Class ANSI 300-600-900-1500
Size: 2" inclusive through to 12"
Temperature: -196°C ~ 450° C (-320° F ~ 850° F)
Actuation: Gear, Pneumatic, Hydraulic, Electric.
Wedge Seal Top Entry Ball Valve
Wedge Seal Top Entry Ball Valve
Class ANSI Class 150-300-600-900-1500
End Connection: NPT-Socket Weld-Butt Weld. [1/2" to 2"],
RF Flanged Type/RTJ Type etc
Size: 1/2" inclusive throught to 16"
Temperature: -196° C ~ 850° C (-320° F ~ 850° F)
INDUSTRIES
• Power Plant
• Oil & Gas
• Petrochemicals
• Desalination
• Steel Mill
DESIGN STANDARD
• API, ASME, ISO
TYPE OF ACTUATION
• Pneumatic
• Motor
• Hydraulic
TYPE OF VALVES
• Top Entry Ball Valve
1/2”~60”
Trunnion & Floating
Casting
• 3 Piece Ball Valve
6”~60”
Trunnion
Casting & Forging
• 2 Piece Ball Valve
1/2”~40”
Trunnion & Floating
Casting & Forging
HARD FACING OPTIONS FOR METAL SEATS
Chrome Plating, Stellite, HVOF (TCC, CCC, others ) Self Fluxing Alloy Powder Coating(Ni Base)
PRESSURE CLASS
• ASME 150# - 2500#
BODY & CAP MATERIAL
• Carbon Steel + (Overlay)
• Stainless Steel
• Duplex Stainless Steel
• Nickel Alloy (Inconel, Incoloy, Hastelloy, Monel)
• Titanium
TRIM MATERIAL
• Carbon Steel + (Overlay or Hard Facing)
• Stainless Steel
• Duplex Stainless Steel
• Nickel Alloy(Inconel, Incoloy, Hastelloy, Monel)
• Titanium
SEAT MATERIAL
• PTFE, PEEK, DEVLON, VITON, METAL
SEAL MATERIAL
• VITON, HNBR, AED, PTFE, LIP SEAL
