Protection Grave : IP 44 and above
Power Source : AC 440V 60HZ 3 (Others Available)
Specification
1) Circulation Pump : 2Set(Option 1set) 4m3/h at 2.0bar Input : 1.5KW Pump Type : LM40-200/205
2) Temp. Controller : Range : 0~110℃ Setting : Heater ON : 40℃ Heater OFF : 45℃
Limit : 95℃ (Setting Value Adjustable)
3) Heater Capacity : 24/36/48/63/77KW
Test Pressure : 6bar
Material : SS400 + Ass'y
Painting Color : MUNSELL No. 7.5 BG 7/2 (Others Available)
| Model | Capa | Dimension(mm) | Weight(Kg) | |||||||
| (KM) | A | B | C | D | E | F | G | H | ||
| SSE-H24 | 24 | 890 | 900 | 900 | 160 | 320 | 1300 | 550 | 770 | 180 |
| SSE-H36 | 36 | 990 | 1000 | 1200 | 160 | 320 | 1300 | 600 | 770 | 200 |
| SSE-H48 | 48 | 1090 | 1100 | 1300 | 160 | 320 | 1300 | 650 | 770 | 220 |
| SSE-H63 | 63 | 1190 | 1200 | 1400 | 250 | 430 | 1500 | 700 | 900 | 250 |
| SSE-H77 | 77 | 1290 | 1300 | 1500 | 250 | 430 | 1500 | 900 | 900 | 300 |
Protection Grave : IP 55
Power Source : AC 440V 60HZ 3 ø(Others Available)
Specification
1) Circulation pump : 180W Pump Type : PDB-86/PB-86
2) Thermostat : Range : 0~110℃ Setting : Heater ON : 40℃ Heater OFF : 45℃ Limit : 95℃ (Setting Value Adjustable)
3) Heater Capacity : 13~18KW
Test Pressure : 6bar
Material : SS400
Painting Color : MUNSELL No. N-6.5(Others Available)
Protection Grave : IP 55
Power Source : AC 440V 60HZ 3 ø(Others Available)
Specification
1) Circulation Pump : 180W 1m3/h at 450m bar 3m3/h at 300m bar Input : 180W Pump Type : SB-860
2) Thermostat : Range : 0~110℃, Setting : Heater ON : 40℃ Heater OFF : 45℃ Limit : 95℃ (Setting Value Adjustable)
3) Heater Capacity : 4.5KW~24KW
Test Pressure : 6bar
Material : SS400
Painting Color : MUNSELL No. N-6.5(Others Available)
