SPECIFICATIONS
| MODEL | DEGR-ST | DEGR-AG | |||
| Item | Standard TIER III Valve | Acid resistant III Valve | |||
| Application Position | RTV/RBV/EGB/CBV | TCO | BCO | CCO/BPCO/ESD | |
| Working Fluids | Exhaust gas | ||||
| Temperature Range | 200℃ ~ 500℃(Max. 550℃) | 25℃ ~ 75℃(Max. 200℃) | 25℃ ~ 75℃(Max. 200℃) or 25℃ ~ 500℃(Max. 550℃) | ||
| Actuator Type | Rack & Pinion, Pneumatic | ||||
| Valve Size | 400A ~ 2000A | 200A ~ 500A | 200A ~ 800A | ||
| End Connection | JIS / DIN / ISO / ANSI Standard | ||||
| Material | Body | Cast Steel, Ductile Cast Iron, Stainless Steel | |||
| Trim | Cast Steel, Ductile Cast Iron, Stainless Steel | ||||
FEATURES
It ensure proper operation of engine and EGR system (Gas-liquid fluid composition) by using 4-7 difference butterfly valves.
Various type according to application position.
There are Standard type and Acid resistant type.
